It will not de-clutch

Broken or bent diaphragm clutch

Broken leaf spring

Possible cause:
  • Fitted with too much force, due to not using special tools

Possible cause:
  • Propeller shaft with excessive play
  • Towing in first gear
  • Wrong shifting
  • Wrong type of clutch

Scuffed diaphragm clutch

Bent leaf spring

Possible cause:

  • Clutch bearing stuck Heavy rotating bearing No clutch bearing play

Possible cause:

  • Propeller shaft with excessive play
  • Towing in first gear
  • No torque wrench used

Broken clutch finger

Primary shaft teeth damaged

Possible cause:

  • Clutch bearing not in centre
  • No clutch bearing play
  • Primary-shaft bearing broken

Possible cause:

  • Too much force was used
  • It was not centered
  • Wrong type of clutch

Worn clutch fingers

Primary shaft teeth worn at one side

Possible cause:

  • Heavy rotating bearing
  • No clutch bearing play

Possible cause:

  • Pilot bearing broken
  • Engine and gearbox are not aligned

Tilting bolt broken

Clutch plate bent, clutch disc facing burned

Possible cause:

  • Engine vibration dampers broken
  • No clutch bearing play
  • Wrong engine adjustment

Possible cause:

  • Overheated clutch
  • The engine was overloaded directly after fitting the clutch

Finger shaft run-out

One side broken clutch

Possible cause:

  • Engine vibration dampers broken
  • Wrong engine adjustment

Possible cause:

  • Gearbox was lowered

Pressure plate broken

Segment springs broken

Possible cause:

  • Overheated due to excessive slipping
  • Excessive slipping due to a worn-out clutch disc
  • Badly functioning clutch control
  • Slave cylinder broken
  • Too much grease on the clutch disc

Possible cause:

  • Pilot bearing broken or missing
  • Engine and gearbox not aligned
  • Gearbox was lowered

Clutch cover bent

Disc facing separated

Possible cause:

  • No torque wrench used
  • Not centered

Possible cause:

  • Overrunning

Clutch cover bent (Opel / Vauxhall)

Burned disc facing

Possible cause:

  • No torque wrench used

Possible cause:

  • Too much grease on the surface
  • Clutch control does not operate properly
  • False grinding of flywheel

Clutch cover bent (VW)

Disc surface oxidised

Possible cause:

  • Not centered

Possible cause:

  • Vehicle was not used for a long period

Worn bolt holes

Possible cause:
  • Unscrewed bolts Engine-gearbox support not or wrong fitted
  The photographs have been kindly made available by LuK Lamellen- und Kupplungsbau, Bühl
