Manufacturer: Saab
Model: 9-5 2,0L
ECU: Saab Trionic T7
Engine code: B205E/F
| À16 | ABS control module |
| Ê143 | AC compressor clutch relay |
| B138 | Accelerator pedal position (APR) sensor |
| 30 | Battery + |
| 31 | Battery - |
| S13 | Brake pedal position (BPP) switch |
| S258 | Clutch pedal position (CPPJ switch |
| Â54 | Crankshaft position (CKP) sensor |
| S79 | Cruise control master switch |
| X80 | Data bus connection |
| À35 | Engine control module (ECM) |
| Ê46 | Engine control relay |
| B24 | Engine coolant temperature (ÅÑÒ) sensor |
| Y104 | Evaporative emission (EVAP) canister purge valve |
| M12 | Fuel pump |
| K20 | Fuel pump relay |
| F | Fuse |
| B72 | Heated oxygen sensor (HO2S) |
| A52 | Ignition amplifier |
| T1 | Ignition coil |
| 15 | Ignition switch - ignition ON |
| Y3 | Injector |
| A5 | Instrument panel |
| Â25 | Intake air temperature (IAT) sensor |
| B69 | Knock sensor (KS) |
| Y152 | Limp-home solenoid |
| K259 | Limp-home solenoid relay |
| B83 | Manifold absolute pressure (MAP) sensor |
| B30 | Mass air flow (MAF) sensor |
| M89 | Throttle position (TP) motor |
| B147 | Throttle position (TP) sensor |
| Y153 | Turbocharger (TC) bypass valve |
| B105 | Turbocharger (TC) wastegate pressure sensor |
| Y68 | Turbocharger wastegate regulating valve |
bl = blue
br = brown
el = cream
ge = yellow
gn = green
gr=grey
nf = neutral
og = orange
rs = pink
rt = red
sw = black
vi = violet
ws = white
hbl = light blue
hgn = light green
rbr = maroon
