Climate Control System Component Location Index #1

Climate Control System Component Location Index #1



SERVICE VALVE
(HIGH-PRESSURE SIDE)SERVICE VALVE
(LOW-PRESSURE SIDE)COMPRESSOR
Replacement,
in the '02 Jazz/Fit Shop Manual
Clutch Check,
in the '02 Jazz/Fit Shop Manual
Clutch Overhaul,
in the '02 Jazz/Fit Shop Manual
Thermal Protector Check,
in the '02 Jazz/Fit Shop Manual
Thermal Protector Replacement,
in the '02 Jazz/Fit Shop Manual
Relief Valve Replacement,
in the '02 Jazz/Fit Shop ManualCONDENSER
(With built-in receiver/dryer)
Replacement,
in the '02 Jazz/Fit Shop ManualSIGHT GLASSEVAPORATOR CORE
(Built-in the heater unit)
Replacement,
in the '02 Jazz/Fit Shop ManualRECEIVER/DRYER
Desiccant replacement,
in the '02 Jazz/Fit Shop Manual
