Front Bumper Removal/Installation

NOTE:

Have an assistant help you when removing and installing the front bumper.
Take care not to scratch the front bumper and body.
Put on gloves to protect your hands.

Remove the front bumper as shown.

Install the bumper in the reverse order of removal, and note these items:

If equipped, make sure the front fog light connectors are plugged in properly.
Make sure the front bumper engages the hooks of the side spacers and upper beams on both sides securely.
Replace any damaged clips.

AFastener LocationsBC: Screw, 2: Screw, 2: Clip, 6ABCABCCCCC6 x 1.0 mm
9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft)SPLASH SHIELDFRONT BUMPERRIGHT
FRONT INNER
FENDERRIGHT
SIDE SPACERHOOKSRIGHT CORNER
UPPER BEAMHOOKSLEFT SIDE SPACERLEFT CORNER
UPPER BEAMLEFT FRONT FOG
LIGHT CONNECTOR
(For some model)RIGHT FRONT FOG
LIGHT CONNECTOR
(For some model)
