Interior Trim Removal/Installation - Tailgate Area

NOTE:

Put on gloves to protect your hands.
When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.
Take care not to bend or scratch the trim and panels.

Remove the trim as shown.

Install the trim in the reverse order of removal, and replace any damaged clips.

PULL POCKETAABBCCCCCCCCCCTAILGATE LOWER
TRIM PANELPINFastener Locations: Hook, 2AB: Clip, 2C: Clip, 10(2)(1)
