M/T Change Lever Assembly Disassembly/Reassembly (5MT)

M/T Change Lever Assembly Disassembly/Reassembly

Prior to reassembling clean all the parts in solvent, dry then, and apply lubricate to any contact surface.

SHIFT LEVERDUST COVEROIL SEAL
Replace.SHIFT ARM
COVERSELECT SPRING COLLARSELECT SPRINGSELECT SPRING PLATEINTERLOCKSHIFT ARMSHIFT LEVER
COVER6 x 1.0 mm
9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft)ROLLERDUST SEAL
Replace.SELECT LEVERBREATHER TUBE8 x 1.25 mm
(3.2 kgf·m, 23 lbf·ft)SPRING WASHER
