Throttle Body Disassembly/Reassembly (Without ETCS)
Throttle Body Disassembly/Reassembly
O-RINGReplace. 6 N·m
(0.6 kgf·m, 4.3 lbf·ft)3.5 N·m
(0.35 kgf·m, 2.5 lbf·ft)EVAP CANISTER
PURGE VALVETHROTTLE BODYIAC VALVETP SENSOR
O-RINGReplace. 6 N·m
(0.6 kgf·m, 4.3 lbf·ft)3.5 N·m
(0.35 kgf·m, 2.5 lbf·ft)EVAP CANISTER
PURGE VALVETHROTTLE BODYIAC VALVETP SENSOR
