Honda Jazz/Fit 2003 · Service Manual

PGM-FI System Component Location Index (L12A/L13A 5MT-KM/KP)

PGM-FI System Component Location Index



SAA3EDJA20326900000DAAD01REAR IGNITION
COILELECTRICAL
LOAD DETECTOR
(ELD)INTAKE AIR TEMPERATURE/
MANIFOLD ABSOLUTE PRESSURE (IAT/MAP)
SENSORReplacement,

in the 2003 Fit/Jazz Shop Manual Supplement, P/N 62SAA22CAMSHAFT
POSITION (CMP)
SENSORReplacement,

in the 2003 Fit/Jazz Shop Manual
Supplement, P/N 62SAA22ENGINE COOLANT
TEMPERATURE
(ECT) SENSORReplacement,
in the 2003 Fit/Jazz Shop Manual
Supplement, P/N 62SAA22INJECTORSReplacement, Replacement,
in the 2003 Fit/Jazz Shop Manual Supplement, P/N 62SAA22KNOCK SENSORCRANKSHAFT POSITION (CKP)
SENSORReplacement,
in the 2003 Fit/Jazz Shop Manual
Supplement, P/N 62SAA22FRONT
IGNITION
COIL



SAA3EDJA20326900000DAAD02SECONDARY HEATED OXYGEN
SENSOR (SECONDARY HO2S)
(SENSOR 2)Replacement,
in the 2003 Fit/Jazz Shop Manual Supplement, P/N 62SAA22PRIMARY HEATED OXYGEN
SENSOR (PRIMARY HO2S)
(SENSOR 1)Replacement,
in the 2003 Fit/Jazz Shop Manual
Supplement, P/N 62SAA22



SAA3EDJA20326900000DAAD03PGM-FI
MAIN RELAY 2PGM-FI
MAIN RELAY 1ENGINE CONTROL
MODULE (ECM)General
Troubleshooting
Information,

in the 2003 Fit/Jazz
Shop Manual Supplement,
P/N 62SAA22DATA LINK CONNECTOR (DLC)General Troubleshooting Information,
 in the 2003 Fit/Jazz Shop Manual Supplement, P/N 62SAA22
Troubleshooting,
 in the 2003 Fit/Jazz Shop Manual Supplement, P/N 62SAA22
