Honda Jazz/Fit 2003 · Service Manual

Fuel and Emissions System Description - Wiring Diagram (5MT-KM/KP)

Fuel and Emissions System Description - Wiring Diagram

ECM Circuit Diagram (cont'd)



SAA3EDLA20300000000CAAD281234567891011121314151617G101ENGINE
WIRE HARNESSENGINE
COMPARTMENT
WIRE
HARNESS



SAA3EDLA20300000000CAAD2918192021222324252627282930313233ENGINE
WIRE
HARNESSENGINE
WIRE
HARNESS



SAA3EEKA20300000000CAAD1424P JUNCTION
CONNECTOR (1)PRIMARY HO2S
(SENSOR 1) (2)APP SENSOR
(3)IAT/MAP SENSOR
(4)CMP SENSOR
(6)EVAP CANISTER
PUERGE VALVE
(5)ECT SENSOR
(7)VSS (8)2P CONNECTOR
(9)ELD (10)UNDER-HOOD
FUSE/RELAY
BOX (13)**TEST TACHOMETER
CONNECTOR (12)UNDER-HOOD
FUSE/RELAY
BOX (11)**UNDER-HOOD
FUSE/RELAY
BOX (14)**UNDER-HOOD
FUSE/RELAY
BOX (15)**UNDER-HOOD
FUSE/RELAY
BOX (16)**THROTTLE
BODY (17)No.1 REAR
IGNITION COIL
(18)No.2 REAR
IGNITION COIL
(19)No.3 FRONT
IGNITION COIL
(20)No.3 REAR
IGNITION COIL
(21)No.4 REAR
IGNITION COIL
(22)No.4 FRONT
IGNITION COIL
(23)No.4 INJECTOR
(24)No.3 INJECTOR
(25)KNOCK SENSOR
(26)No.2 INJECTOR
(27)No.2 FRONT
IGNITION COIL
(28)ALTERNATOR
(29)No.1 INJECTOR
(30)No.1 FRONT
IGNITION COIL
(31)EGR VALVE
(32)CKP SENSOR
(33)NOTE:Connector with male terminals (double outline): view from terminal side·Connector with female terminals (single outline): view from wire side**: Connector with female terminals (single outline): view from terminal side·

ECM Circuit Diagram (cont'd)

SAA3EEKA20300000000CAAD1512345678910111213141516171819202122232425ENGINE
COMPARTMENT
WIRE
HARNESSDASHBOARD
WIRE HARNESS



SAA3EEKA20300000000CAAD162627282930DASHBOARD
WIRE HARNESS



SAA3EEKA20300000000CAAD1713P CONNECTOR (1)6P CONNECTOR
(2)GAUGE B (3)GAUGE A (4)UNDER-DASH
FUSE/RELAY
BOX (19)UNDER-DASH
FUSE/RELAY BOX (20)UNDER-DASH
FUSE/RELAY BOX (21)UNDER-DASH
FUSE/RELAY BOX (22)UNDER-DASH
FUSE/RELAY BOX (23)UNDER-DASH
FUSE/RELAY
BOX (24)14P CONNECTOR (26)ECM CONNECTOR
No.1 (9P) (27)**3P CONNECTOR (25)ECM CONNECTOR
No.3 (52P) (28)**ECM CONNECTOR
No.5 (9P) (30)**ECM CONNECTOR
No.4 (40P) (29)**IGNITION SWITCH
(5)DATA LINK
CONNECTOR (6)**SECONDARY HO2S
(SENSOR 2) (7)FUEL PUMP (8)BRAKE PEDAL
POSITION SWITCH (9)UNDER-DASH
FUSE/RELAY BOX (10)UNDER-DASH
FUSE/RELAY BOX (11)RELAY BLOCK
(14)**UNDER-DASH
FUSE/RELAY BOX (12)UNDER-DASH
FUSE/RELAY BOX (13)RELAY BLOCK
(PGM-FI MAIN
RELAY 2) (15)**RELAY BLOCK
(PGM-FI MAIN
RELAY 1) (16)**RELAY BLOCK
(17)**UNDER-DASH
FUSE/RELAY
BOX (18)NOTE:Connector with male terminals (double outline): view from terminal side·Connector with female terminals (single outline): view from wire side**: Connector with female terminals (single outline): view from terminal side·
