Heater Component Location Index

BLOWER UNIT
Removal and Installation, BLOWER UNIT COMPONENTS
Replacement, DUST AND POLLEN FILTER
(With A/C)
Replacement, HEATER UNIT/CORE
Replacement, EVAPORATOR TEMPERATURE
SENSOR (With A/C)
Test, HEATER CONTROL PANEL
Removal and Installation,
Disassembly and Reassembly, A/C SWITCH (With A/C)
Removal and Installation,
Test, NOTE: LHD type is shown, RHD type is symmetrical.RECIRCULATION
CONTROL CABLE
Adjustment, MODE CONTROL CABLE
Adjustment, HEATER FAN SWITCH
Test, AIR MIX CONTROL CABLE
Adjustment, BLOWER RESISTOR
