Front Seat Disassembly/Reassembly - With Manual Height Adjustable

Front Seat Disassembly/Reassembly - With Manual Height Adjustable

For some models: SRS components are located in this area. Review the SRS component locations, and the precautions and procedures in the SRS section before performing repairs or service.

NOTE:

• Take care not to tear the seams or damage the seat covers.

• Put on gloves to protect your hands.

• When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

• The left side seat is shown, the right side seat is symmetrical.


Disassemble the seat as shown.

Reassemble the seat in the reverse order of disassembly, and note these items:

•

• Apply multipurpose grease to the moving portion of the seat track.

• To prevent wrinkles in the seat cushion cover, stretch the material evenly over the pad.
