Roof Wire Harness Locations (LHD)

Roof Wire Harness Locations



LHD type:

SAA2E03J54283251701DBAD01ROOF WIRE HARNESS
(With sunroof)UNDER-DASH FUSE/RELAY BOX



LHD type:

SAA2E03J54283251701DBAD02ROOF WIRE HARNESS
(Without sunroof)UNDER-DASH FUSE/RELAY BOX
