Honda Jazz/Fit 2004 · Service Manual
EPS Wire Harness Locations (RHD)
EPS Wire Harness Locations
RHD type:
G451
UNDER-DASH FUSE/RELAY BOX
EPS WIRE HARNESS
G451UNDER-DASH FUSE/RELAY BOXEPS WIRE HARNESSG451UNDER-DASH FUSE/RELAY BOXEPS WIRE HARNESSG451UNDER-DASH FUSE/RELAY BOXEPS WIRE HARNESS
