A/T Shift Lever Disassembly/Reassembly (L15A CVT)

A/T Shift Lever Disassembly/Reassembly



SHIFT LEVER KNOBA/T GEAR POSITION
INDICATOR PANELSHIFT LEVER COVERA/T GEAR POSITION
INDICATOR
PANEL LIGHT BULBSCREW
3 N·m (0.3 kgf·m, 2 lbf·ft)
Apply non-hardening thread
lock sealant.SILICONE
GREASESHIFT LEVER ASSEMBLYSHIFT LOCK SOLENOIDPLUNGER SPRINGSHIFT LOCK
SOLENOID PLUNGERSILICONE
GREASEPARK PIN SWITCH
CONNECTORPARK PIN SWITCH
