Exhaust Manifold Removal and Installation
Exhaust Manifold Removal and Installation
| 1. | Remove the cover and exhaust manifold bracket, then remove the exhaust manifold.
 GASKETReplace.EXHAUST MANIFOLDCOVEREXHAUST MANIFOLD BRACKET8 x 1.25 mm 22 N·m (2.2 kgf·m, 16 lbf·ft) Replace. Tighten the bolt in steps, alternating side-to-side10 x 1.25 mm 44 N·m (4.5 kgf·m, 33 lbf·ft) Replace.8 x 1.25 mm 24 N·m (2.4 kgf·m, 17 lbf·ft)WASHER8 x 1.25 mm 24 N·m (2.4 kgf·m, 17 lbf·ft)GASKET Replace. |
| 2. | Install the exhaust manifold and tighten the bolts/nuts in a crisscross pattern in two or three steps, beginning with the inner bolt. |
| 3. | Install the other parts in the reverse order of removal. |
