Clutch Slave Cylinder Overhaul (5MT)

Clutch Slave Cylinder Overhaul



SLAVE CYLINDER BODY
Check the cylinder wall
for scoring and wear.O-RING
Replace.BLEEDER SCREW
8 N·m
(0.8 kgf·m, 5.8 lbf·ft)BLEEDER SCREW CAP(Brake Assembly Lube)SLAVE CYLINDER SPRING
Install with small end facing piston.PISTON CUP
Replace.SLAVE CYLINDER PISTON
Check for wear and damage.BOOT
Check that it fits securely
over the cylinder body.PUSH RODROLL PINS
Replace.Urea Grease UM264
(P/N 41211 - PY5 - 305)(Brake Assembly Lube)
