Fuel Supply System Component Location Index (5MT-KG/KE/KR)

Fuel Supply System Component Location Index

FUEL FILL CAPFUEL TUBE/QUICK-CONNECT FITTINGS
Precautions,
Removal,
Installation, FUEL PUMP
Circuit Troubleshooting,

Replacement, FUEL FILTER
Replacement, FUEL GAUGE SENDING UNIT
Test/ FUEL PRESSURE REGULATOR
Replacement, FUEL TANK
Replacement, FUEL FEED PIPEFUEL RAILFUEL VAPOR PIPESUCTION LINE
Inspection, BREATHER
LINE
Inspection,

LHD model:

PGM-FI MAIN RELAY 2PGM-FI MAIN RELAY 1INERTIA SWITCH
Troubleshooting, ENGINE CONTROL
MODULE (ECM)

RHD model:

PGM-FI MAIN RELAY 1PGM-FI MAIN RELAY 2INERTIA SWITCH
Troubleshooting, ENGINE CONTROL
MODULE (ECM)
