Honda Jazz/Fit 2005 · Service Manual

Keyless/Power Door Lock System Component Location Index (RHD)

Keyless/Power Door Lock System Component Location Index

RHD type:

SAA4EQ4J46643400000DAAD01LEFT REAR DOOR SWITCHFRONT PASSENGER'S SUPER LOCKING*1
ACTUATOR/KNOB SWITCHFRONT PASSENGER'S DOOR LOCK ACTUATOR*2FRONT PASSENGER'S KEY CYLINDER SWITCH*1FRONT PASSENGER'S DOOR SWITCHDRIVER'S KEY
CYLINDER SWITCH*1FUEL FILL DOOR LOCK ACTUATOR
(KU, KQ model)POWER WINDOW
MASTER SWITCH
(Has built-in driver's
door lock switch)DRIVER'S SUPER LOCKING
ACTUATOR/KNOB SWITCH*1
DRIVER'S DOOR LOCK
ACTUATOR/KNOB SWITCH*2DRIVER'S DOOR SWITCHRIGHT REAR SUPER LOCKING ACTUATOR/
KNOB SWITCH*1
RIGHT REAR DOOR LOCK ACTUATOR*2RIGHT REAR DOOR SWITCHLEFT REAR SUPER LOCKING ACTUATOR/KNOB SWITCH*1
LEFT REAR DOOR LOCKING ACTUATOR*2TAILGATE LATCH SWITCH
TAILGATE LOCK ACTUATOR
TAILGATE LOCK KNOB SWITCH*1TAILGATE KEY
CYLINDER SWITCH*1*1: KE model
*2: Except KE model

RHD type:

SAA4EQ4J46643400000DAAD02TRANSMITTER
Test,
Programming, LOCK BUTTONIGNITION KEYUNLOCK BUTTONGAUGE ASSEMBLY
(Has built in the super locking
or power door lock control circuit)
Input test, IGNITION KEY SWITCHKEYLESS RECEIVER UNIT
Input test, UNDER-DASH FUSE/RELAY BOXLEFT ACTIVATION INDICATOR RELAY
Test, RIGHT ACTIVATION INDICATOR RELAY
Test, POWER DOOR UNLOCK/
FUEL FILL DOOR UNLOCK RELAY
Test, POWER DOOR LOCK/
FUEL FILL DOOR UNLOCK RELAY
Test, LEFT SUPER LOCKING RELAY
(KE model)
Test, RIGHT SUPER LOCKING RELAY
(KE model)
Test,
