VSA System Component Location Index (With VSA)

VSA System Component Location Index



UNDER-DASH
FUSE/RELAY BOXUNDER-HOOD
FUSE/RELAY BOXLEFT-FRONT WHEEL SENSOR
Inspection,
in the Shop Manual, P/N 62SAA00
Replacement,
in the Shop Manual, P/N 62SAA00VSA MODULATOR-CONTROL UNIT
Removal and Installation, RIGHT-FRONT WHEEL SENSOR
Inspection,
in the Shop Manual, P/N 62SAA00
Replacement,
in the Shop Manual, P/N 62SAA00RIGHT-REAR WHEEL SENSOR
Inspection,
in the Shop Manual, P/N 62SAA00
Replacement,
in the Shop Manual, P/N 62SAA00DATA LINK CONNECTOR (16P)LEFT-REAR
WHEEL SENSOR
Inspection,
in the Shop Manual, P/N 62SAA00
Replacement,
in the Shop Manual, P/N 62SAA00STEERNG ANGLE SENSOR
Replacement, VSA OFF SWITCH
Test, YAW REATE/LATERAL
ACCELERATION SENSOR
Replacement, LHD type is shown, RHD type is symmetrical.
