SYSTEM DIAGRAM

System information

Transmitting ECU (Transmitter)	Receiving ECU	Signals	Communication method
Combination Meter Assembly	Center Airbag Sensor Assembly	Vehicle speed signal	BEAN
Center Airbag Sensor Assembly	Combination Meter Assembly	Driver seat buckle switch signal Passenger seat buckle switch signal Diagnosis signal (DTC) SRS warning light blink demand signal SRS warning light ON demand signal Passenger seat occupant detection signal	BEAN
Center Airbag Sensor Assembly	Body ECU	Driver seat buckle switch signal	BEAN
ECM	Center Airbag Sensor Assembly	E/G speed signal Test mode signal Throttle opening angle information signal Stop signal	CAN-BEAN
Hybrid Vehicle Control ECU	Center Airbag Sensor Assembly	Shift position signal	CAN-BEAN
