POWER STEERING CONTROL UNIT
EPS
Exploded View
|
1. |
Power steering control unit |
|
|
|
|
 : Vehicle front |
|||||
Removal and Installation
REMOVAL- 1.Remove glove box assembly. Refer to Exploded View.
- 2.Remove instrument assist lower panel. Refer to Exploded View.
- 3.Remove power steering control unit screws.
- 4.Remove power steering control unit (1).
- 5.Disconnect power steering control unit connector.
INSTALLATIONInstall in the reverse order of removal.
