P1238, P2119 ELECTRIC THROTTLE CONTROL ACTUATOR
VR38
P1238 P2119
Description
Electric throttle control actuator consists of throttle control motor, throttle position sensor, etc.
The throttle control motor is operated by the ECM and it opens and closes the throttle valve.
The throttle position sensor detects the throttle valve position, and the opening and closing speed of the throttle valve and feeds the voltage signals to the ECM. The ECM judges the current opening angle of the throttle valve from these signals and the ECM controls the throttle control motor to make the throttle valve opening angle properly in response to driving condition.
DTC Logic
DTC DETECTION LOGIC|
DTC No. |
Trouble diagnosis name |
DTC detecting condition |
Possible cause |
|
|
P1238 |
Electric throttle control actuator (bank 2) |
A) |
Electric throttle control actuator does not function properly due to the return spring malfunction. |
|
|
B) |
Throttle valve opening angle in fail-safe mode is not in specified range. |
|||
|
C) |
ECM detect the throttle valve is stuck open. |
|||
|
P2119 |
Electric throttle control actuator (bank 1) |
A) |
Electric throttle control actuator does not function properly due to the return spring malfunction. |
|
|
B) |
Throttle valve opening angle in fail-safe mode is not in specified range. |
|||
|
C) |
ECM detect the throttle valve is stuck open. |
|||
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
