WARNING FUNCTION

The warning function are as per the following and are given to the user as warning information and warnings using combinations of Intelligent Key warning buzzer, KEY warning lamp, key slot illumination and information display in combination meter.

• Intelligent Key system malfunction
• OFF position warning
• P position warning
• ACC warning
• Take away warning
• Door lock operation warning
• Key warning
• Intelligent Key insert information
• Engine start information
• Steering lock information
• Intelligent key low battery warning
• Key ID warning

Once one of the following conditions below is established, alert or warning will be executed.

Warning/Information functions		Operation procedure
Intelligent Key system malfunction		When a malfunction is detected in BCM, “KEY” warning lamp will illuminate.
OFF position warning	For internal	Ignition switch: ACC position. Door switch (driver side): ON (Door is open).
	For external	OFF position warning (for internal) is in active mode, driver side door is closed. NOTE： OFF position (for external) active only when each of the sequence has occurred as per the following: P position warning → ACC warning → OFF position warning (for internal) → OFF position warning (for internal)
P position warning		Shift position: Any position except the P position. Engine is running to stopped (ignition switch is ON to OFF).
ACC warning		When P position warning is in active mode, shift position changes from the P position. Ignition switch: ACC position.
Take away warning	Door is open to close	Ignition switch: Any position except the LOCK position. Door switch: ON to OFF (door is open to close). Intelligent Key can not be detected inside the vehicle.
	Door is open	Door switch: ON (door is open). Key ID verification every 5 seconds when registered Intelligent Key can not be detected inside the vehicle.
	Push button-ignition switch operation	Ignition switch: Any position except the LOCK position. Press push-button ignition switch. Intelligent Key can not be detected inside the vehicle.
	Intelligent Key is removed from key slot	When Intelligent Key is removed from key slot, Intelligent Key can not be detected inside the vehicle.
Door lock operation warning	Request switch operation	When request switch is pushed (lock operation) under the following conditions. All doors are closed. All doors are unlocked. Intelligent Key is inside vehicle.
	Intelligent Key button operation	When Intelligent Key button is pushed (lock operation) under the following conditions. Door switch: ON (any door is open). For 3 seconds after Intelligent Key is removed from key slot.
Key warning		Ignition switch is in the OFF position. Driver side door switch: ON (driver side door is open). Intelligent Key is inserted in key slot.
Intelligent Key insert information		Door switch: ON to OFF (door is open to close). Ignition switch: OFF to ON position. Intelligent Key is out of key slot. Intelligent Key can not be detected inside the vehicle.
Engine start information	Ignition switch is in the ON position	Ignition switch: ON position. Shift position: P position. Engine is stopped.
	Ignition switch is in any position except the ON position	Ignition switch: Any position except the ON position. Shift position: P position. Intelligent Key is inserted in key slot or Intelligent Key can be detected inside the vehicle.
Steering lock information		When steering lock can not be released after ignition switch is turned ON.
Intelligent Key low battery warning		When Intelligent Key is battery low, BCM is detected after ignition switch is turned ON.
Key ID warning		When registered Intelligent Key can not be detected inside the vehicle after ignition switch is turned ON.

The following table shows the alarm or warning methods with chime.
Information display (combination meter), “KEY” indicator or key slot illumination when the warning conditions are met.

Warning/Information functions		“KEY” warning lamp	Information display (combination meter)	Key slot illumination	Warning chime
					Combination meter buzzer	Intelligent Key warning buzzer
Intelligent Key system malfunction		Illuminate	—	—	—	—
OFF position warning	For internal	—	—	—	Activate	—
	For external	—	—	—	—	Activate
P position warning		—		—	Activate	—
ACC warning		—		—	—	—
Take away warning	Door is open to close	—		Blink	Activate	Activate
	Door is open	—		Flash	—	—
	Push-ignition switch operation	—		Flash	Activate	—
	Intelligent Key is removed from key slot	—		Flash	—	—
Door lock operation warning	Request switch operation	—	—	—	—	Activate
	Intelligent Key operation	—	—	—	—	Activate
Key ID warning		—		—	—	—
Key warning		—		Flash	Activate	—
Intelligent Key insert information		—		Flash	—	—
Engine start information		—		—	—	—
Steering lock information		—		—	—	—
Intelligent Key low battery warning		—		—	—	—

Parts marked with × are the parts related to operation.

Warning function

Intelligent Key

Key slot

Ignition switch

Door switch

Door request switch

Inside key antenna

Outside key antenna

Intelligent Key warning buzzer

Combination meter warning buzzer

CAN communication system

BCM

Combination meter display

Key slot illumination

Park position switch

“KEY” warning lamp

Intelligent Key system malfunction

×

×

×

OFF position warning

For internal

×

×

×

×

For external

×

×

×

P position warning

×

×

×

×

×

×

ACC warning

×

×

×

×

×

×

Take away warning

Door is open or close

×

×

×

×

×

×

×

×

×

Door is open

×

×

×

×

×

×

×

Push-ignition switch operation

×

×

×

×

×

×

×

×

Intelligent Key is removed from key slot

×

×

×

×

×

×

×

Door lock operation warning

×

×

×

×

×

×

×

×

Key ID warning

×

×

×

×

×

×

×

Key warning

×

×

×

×

×

×

×

×

Intelligent Key insert information

×

×

×

×

×

×

×

×

×

Engine start information

Ignition switch is in the ON position

×

×

×

×

×

×

×

×

Ignition switch is in any position except the ON position

×

×

×

×

×

×

×

Steering lock information

×

×

×

×

Intelligent Key low battery warning

×

×

×

×

×
