To Remove:
- Disconnect or remove the following
- Battery ground cable
| Intake Air Temp Sensor
|
- Throttle position sensor connector
- Throttle position sensor holding screws
- Throttle position sensor
To Install:
- Install or connect the following
| Intake Air Temp Sensor
|
- Throttle position sensor
- Throttle position sensor holding screws
- Throttle position sensor connector
- Battery ground cable
- Tightening torque: 2.4 N.m (1.7 ft-lb)
CAUTION
When installing throttle position sensor, adjust to the specified data.
