Rear Fog Light Assembly Removal and Installation (If Equipped)

Precautions: Precautions for Headlight Auto Leveling System Service · Precautions for Body, Cab and Accessories · General safety (00)

Removal

1)Disconnect connector (1) and clamps (2).

2)Remove rear fog light nuts (3), and remove rear fog light assembly (4).

3)Remove bulb, if necessary.

Installation

Reverse removal procedure.
