Rearview Camera Removal and Installation
Precautions: Precautions for Audio Visual / Navigation · Precautions for Body, Cab and Accessories · General safety (00)
Removal
1)Remove rear end license garnish.
2)Disconnect negative (–) cable at battery.
3)Disconnect rearview camera connector (1).
4)Detach rearview camera connector from rear end door (2).
5)Remove rearview camera (3) from rear end door while holding claws (4) pressed in arrow directions.
Installation
Reverse removal procedure.
