REMOVAL
FRONT
NOTE: Front rotors and hub/bearings are matched mounted for minimum lateral runout. Before removing the rotor, mark the rotor and hub/bearing to maintain original orientation.
1. Raise and support the vehicle.
2. Remove wheel and tire assembly.
3. Remove the caliper adapter mounting bolts (3) and remove the caliper adapter from the steering knuckle.
4. Secure caliper anchor assembly to nearby suspension part with a wire. Do not allow brake hose to support caliper weight.
5. Remove and discard the o-ring (2) securing the disc brake rotor (1) on the hub.
6. Remove the disc brake rotor from hub/bearing.
REAR
1. Raise and support the vehicle.
2. Remove wheel and tire assembly.
3. Remove the caliper slide bolts (4).
4. Remove caliper (1).
5. Secure caliper assembly (1) to nearby suspension part with wire. Do not allow brake hose to support caliper weight.
6. Remove and discard the o-ring (2) securing rotor (1) to axle studs.
7. Remove rotor (1) off axle studs.
