REMOVAL
LEFT SIDE
1. Raise and support the vehicle.
2. Support the rear axle.
3. Lower the fuel tank in order to gain access to the bolt (Refer to 14 - FUEL SYSTEM/FUEL DELIVERY/FUEL TANK - REMOVAL).
4. Remove the upper suspension arm nut (2) and bolt (3) from the axle bracket.
5. Remove the nut (1) and bolt (7) from the frame rail and remove the upper suspension arm (2).
RIGHT SIDE
1. Raise and support the vehicle.
2. Support the rear axle.
3. Remove the upper suspension arm nut (2) and bolt (3) from the axle bracket.
4. Remove the nut (1) and bolt (7) from the frame rail and remove the upper suspension arm (2).
