INSTALLATION
3.0L - DIESEL
1. Clean EGR valve sealing surfaces.
2. Lubricate the seal and install the EGR valve in intake manifold. Tighten EGR valve retaining bolts to 9 N·m (80 lbs.in).
3. Connect the EGR valve wiring harness connector.
4. Install engine cover.
5. Connect the negative battery cable.
