SPLASH SHIELD-FRONT WHEELHOUSE
REMOVAL
1. Remove the front fasteners (1).
2. Remove the remaining fasteners (3 - 5) and remove the splash shield (6).
INSTALLATION
1. Install the splash shield, (6) and install the fasteners (3 - 5).
2. Install the front fasteners (1).
