INSTALLATION
GAS ENGINE
1. Slide hose clamps (2) onto both ends of the power steering fluid supply hose (1) far enough to clear the fittings on the reservoir and pump once the hose is installed.
2. Place the pump end of the supply hose (1) onto the pump (3) supply fitting. Expand the hose clamp (2) and slide it over the hose and pump supply fitting. Secure the clamp once it is past the bead formed into the fluid supply fitting.
3. Expand the hose clamp (4) at the fluid reservoir (5) and slide it over the hose and fitting. Secure the clamp once it is past the bead formed into the fluid reservoir fitting.
4. Perform the POWER STEERING PUMP BLEED PROCEDURE. (Refer to 19 - STEERING - STANDARD PROCEDURE)
5. Check for leaks at all hose connections.
DIESEL ENGINE
1. Slide hose clamps onto both ends of the power steering fluid supply hose far enough to clear the fittings on the reservoir and pump once hose is installed.
2. Expand the hose clamp (4) at the fluid reservoir end (5) and slide it over the hose and fitting. Secure the clamp once it is past the bead formed into the fluid reservoir fitting.
3. Place the pump end of the supply hose (1) onto the pump supply fitting (2). Expand the hose clamp and slide it over the hose and pump supply fitting. Secure the clamp (3) once it is past the bead formed into the fluid supply fitting.
4. Fill and bleed the power steering system. (Refer to 19 - STEERING - STANDARD PROCEDURE)
5. Check for leaks.
6. Install the engine appearance cover.
