LEVER-SHIFT
REMOVAL
1. Disconnect select cable (2) from select lever (1) and cable bracket.
2. Using a pin punch, remove the select roll pin from lever (4).
3. Pull up and remove the select lever (4) from the transaxle select shaft.
INSTALLATION
1. Install select lever to shaft and fasten with NEW roll pin.
2. Install select cable to bracket. Fasten with clip.
3. Install select cable to select lever.
