FLUID RESERVOIR
REMOVAL
1. Install a brake pedal prop rod.
2. Remove reservoir cap and remove fluid with a clean suction gun.
3. Remove the wire connector from the brake fluid level sensor (2).
4. Remove the fluid reservoir (1) from the master cylinder (3).
5. Pull the reservoir straight up out of the cylinder (2).
6. Remove and discard grommets from the cylinder body (2).
7. Remove the fluid level sensor (1) from the reservoir (2) if needed.
INSTALLATION
1. Install the fluid level sensor (1) into the reservoir (2) if removed.
2. Lubricate new o-rings (2) with clean brake fluid.
CAUTION: Do not use tools to install the o-rings. Tools may cut, or tear the o-rings. Install the o-rings using finger pressure only.
3. Start reservoir in o-rings then press the reservoir straight down to seat the reservoir into the cylinder o-rings.
CAUTION: Do not rock the reservoir during installation.
4. Verify retaining tabs are seated.
5. Install the wire connector to the brake fluid level sensor (2).
6. Remove brake pedal prop rod.
7. Fill master cylinder.
