INSTALLATION
SERVOMOTOR
1. Install actuator rod onto servomotor (4).
2. Install circlip (1).
3. Position servomotor and actuator rod onto turbocharger (5).
4. Install mounting bolts (3). Tighten bolts to 8 N·m (70 lbs.in).
5. Install circlip on the actuator rod at the turbocharger end (2).
6. Connect electrical connector (6).
7. Install the turbo heat shield.
8. Connect negative battery cable.
9. Install air cleaner housing.
10. Connect negative battery cable.
