INSTALLATION
LEFT SIDE
NOTE: All torques should be done with vehicle on the ground with full vehicle weight.
1. Position the upper suspension arm (2) in the frame rail bracket.
2. Install the mounting bolt (7) and nut (1) tighten to 129 N·m (95 ft. lbs.).
3. Position the upper suspension arm (4) in the axle bracket.
4. Install the mounting bolt (3) and nut (2) tighten to 136 N·m (100 ft. lbs.).
5. Raise the fuel tank back into place and secure (Refer to 14 - FUEL SYSTEM/FUEL DELIVERY/FUEL TANK - INSTALLATION).
6. Remove the supports and lower the vehicle.
RIGHT SIDE
NOTE: All torques should be done with vehicle on the ground with full vehicle weight.
1. Position the upper suspension arm (2) in the frame rail bracket.
2. Install the mounting bolt (7) and nut (1) tighten to 129 N·m (95 ft. lbs.).
3. Position the upper suspension arm (4) in the axle bracket.
4. Install the mounting bolt (3) and nut (2) tighten to 136 N·m (100 ft. lbs.).
5. Remove the supports and lower the vehicle.
