COWL TRIM COVER
REMOVAL
1. Using a trim stick C-4755 or equivalent, lift up the front edge of the lower B-pillar trim (4) and position aside. (Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER TRIM - REMOVAL)
2. Remove the cowl trim cover (3) by pulling it away from the A-pillar and releasing the clips (1 and 2).
INSTALLATION
1. Install the cowl trim cover (3) and seat the retaining clips (1 and 2).
2. Position the B-pillar trim panel (4) and seat the retaining clips.
