2007 Wrangler JK Factory Service Manual 23 - BODY

GLOVE BOX

REMOVAL




1. Open the glove box (1) and squeeze the stop tabs (2) inward.



2. Lower the glove box (2) and release the hinges (1) and remove the glove box.

INSTALLATION




1. Position the glove box tabs onto the hinges (1).



2. Close the box (1) and squeeze the stop tabs (2) inward and engage into the instrument panel.
