2012 Jeep Wrangler JK Factory Service Manual 23 - Body

CATCH, Hood

REMOVAL

REMOVAL

  1. Open the hood.

    2.
  2. Remove the nuts (2) and remove the hood catch (1).

    3.
  3. Remove the nuts (1) and remove the catch bracket (2).

    4.

INSTALLATION

INSTALLATION

  1. Install the catch bracket (2) and install the nuts (1).

    2.
  2. Tighten the nuts to 7 N·m (5 ft. lbs.).

    3.
  3. Install the hood catch (1) and install the nuts (2).

    4.
  4. Tighten the nuts to 15 N·m (11 ft. lbs.).

    5.
