REMOVAL & INSTALLATION

1. Disconnect the negative battery cable.
2. Raise and support the vehicle safely.
3. Detach the electrical harness connector from the switch, then remove the unit from the oil filter head.

   To install:

4. Apply a thin bead of sealant to the threaded portion of the oil pressure sensor. Do not allow sealer to contact the end of the threaded portion of the sensor.
5. Install the sensor and tighten to 8 ft. lbs. (12 Nm). Do not overtighten the sensor.
6. Attach the electrical harness connector to the sensor.
7. Carefully lower the vehicle, then connect the negative battery cable.
