Door Panels

REMOVAL & INSTALLATION

Fig. 1: Loosen the door handle screws and remove the door handle

Fig. 2: Special tools are available to remove the window handle

  1. Remove the screws which hold the gusset cover, and detach the cover.
  2. Remove screws which hold pull handle and other screws located further inside.
  3. Remove the remote handle cover.
  4. Remove the window handle by unfastening the retaining clip.

    Fig. 3: Loosen the screws retaining the door handle cover and remove the cover

    Fig. 4: Use a clip puller to disengage the trim panel clips . . .

    Fig. 5: . . . then remove the trim panel

  5. Remove the clip attached to trim panel using Clip Puller (925580000) or equivalent.
  6. Remove the trim panel.
  7. Installation is the reverse of removal.
