Passenger Air Bag Deactivation Indicator Inspection (If Equipped)
Precautions: Precautions for Air Bag System Service · Precautions for Handling and Storage of Air Bag System Components · Precautions for Disposal of Air Bag and Seat Belt Pretensioner · Precautions for Restraint · General safety (00)
1)Remove passenger air bag deactivation indicator.
2)Check “PASSENGER AIR BAG OFF” and “PASSENGER AIR BAG ON” indicators as follows. If any faulty conditions is found, replace hazard switch.
a)Connect battery positive (+) terminal to terminal “9” and negative (–) terminal to terminal “10” as shown.
b)Check that “PASSENGER AIR BAG OFF” indicator (1) lights up.
c)Connect battery positive (+) terminal to terminal “4” and check that “PASSENGER AIR BAG OFF” indicator reduces an illumination.
d)Connect battery positive (+) terminal to terminal “9” and negative (–) terminal to terminal “3” as shown.
e)Check that “PASSENGER AIR BAG ON” indicator (1) lights up.
f)Connect battery positive (+) terminal to terminal “4” and check that “PASSENGER AIR BAG ON” indicator reduces an illumination.
