CABLE-SATELLITE ANTENNA
REMOVAL
1. Disconnect the battery negative cable.
2. Remove the top.
3. Remove the B-pillars. (Refer to 23 - BODY/INTERIOR/B-PILLAR TRIM - REMOVAL).
4. Remove the cowl trim. (Refer to 23 - BODY/INTERIOR/COWL TRIM COVER - REMOVAL).
5. Remove the glove box.
6. Remove the instrument panel speaker. (Refer to 8 - ELECTRICAL/AUDIO/SPEAKER - REMOVAL).
7. Remove the satellite antenna cable.
INSTALLATION
1. Install the satellite antenna cable.
2. Install the instrument panel speaker. (Refer to 8 - ELECTRICAL/AUDIO/SPEAKER - INSTALLATION).
3. Install the glove box.
4. Install the cowl trim.
5. Install the lower B-pillar trim. (Refer to 23 - BODY/INTERIOR/B-PILLAR TRIM - INSTALLATION).
6. Install the top.
7. Connect the battery negative cable.
