REMOVAL

3.8L

1. Drain cooling system (Refer to 7 - COOLING - STANDARD PROCEDURE).
2. Raise vehicle on hoist.
3. Detach power cord plug from heater.
4. Loosen screw in center of heater. Remove heater assembly.
