| Fig. 1: Ignition module mounted below the steering column
|
NOTE: The ignition module is located below the steering column
inside the vehicle.
- Disconnect the negative battery cable.
- Remove the retaining screws securing the interior panel below the steering
column. Disconnect any harnesses that may be attached to the panel, and place
the panel aside.
- Remove the retaining bolts securing the ignition module to the bracket.
- Unfasten the large and small connectors attached to the ignition module.
- Installation is the reverse of removal. Secure all components accordingly.
